Portable ECG monitors are widely used in home healthcare, hospitals, ambulances, telemedicine, cardiac screening, and remote patient monitoring. These devices collect cardiac electrical signals and may record, store, display, or wirelessly transmit ECG data for further review.
As ECG equipment becomes smaller and more wearable, battery performance directly affects monitoring duration, signal stability, data transmission reliability, device weight, and patient comfort.
LithoTop provides customized lithium battery solutions for portable ECG monitor manufacturers, including ultra-thin LiPo batteries, ultra-small LiPo batteries, rechargeable Li-ion battery packs, and Li-MnO₂ primary batteries.
Challenges of Portable ECG Monitor Battery Design
Stable Signal Acquisition
ECG equipment needs a stable power supply to support reliable signal acquisition, processing, storage, and data transmission.
- Stable voltage output
- Low voltage fluctuation
- Consistent low-current discharge
- Reliable operation during wireless transmission
Long Monitoring Duration
Wearable ECG devices and Holter monitors may need to record cardiac activity continuously for extended periods.
- Long operating time
- Low self-discharge
- Efficient standby performance
- Consistent capacity retention
Compact and Lightweight Design
Portable and wearable cardiac monitors require small batteries that do not increase device size or patient burden.
- Ultra-thin profiles
- Ultra-small dimensions
- Lightweight structures
- Custom form factors
Wireless Data Transmission
Bluetooth, Wi-Fi, and cellular communication modules can create intermittent power peaks during data transmission.
- Stable pulse-current output
- Low internal resistance
- Reduced voltage drop
- Reliable data transmission
Safety and Medical Reliability
Portable ECG monitors may remain close to the patient for long periods, making battery safety and manufacturing consistency essential.
- Overcharge protection
- Over-discharge protection
- Short-circuit protection
- Temperature monitoring
- Grade-A lithium cells
- Complete production inspection
LithoTop Battery Solutions for Portable ECG Monitors
Ultra-Thin LiPo Batteries
- Thin profile for wearable ECG patches
- Lightweight structure for patient comfort
- High energy density
- Stable low-current discharge
- Custom dimensions
- Optional PCM and NTC integration
Ultra-Small LiPo Batteries
- Ultra-compact battery dimensions
- Rechargeable design
- Stable voltage output
- Custom wire and connector options
- Lightweight construction
- OEM and ODM support
Li-ion Battery Packs
- Higher capacity for longer operation
- Stable power for displays and communication systems
- Custom series and parallel configurations
- Replaceable or built-in pack designs
- Optional PCM or BMS protection
- Custom enclosures and chargers
Li-MnO₂ Primary Batteries
- Stable 3.0V output
- Low self-discharge
- Long storage life
- Maintenance-free operation
- Reliable low-current performance
- Suitable for disposable ECG devices
Portable ECG Monitor Battery Features
- Compact and lightweight construction
- Stable voltage output
- Long continuous monitoring time
- High energy density
- Low self-discharge
- Reliable pulse-current support
- Custom size and connector options
- Optional PCM and temperature sensing
- Grade-A battery cells
- OEM and ODM manufacturing support
Typical Battery Specifications for Portable ECG Monitors
| Parameter | Typical Range |
|---|---|
| Voltage | 3.0V / 3.7V / 3.85V / 7.4V |
| Capacity | 50mAh – 10000mAh |
| Battery Type | LiPo / Li-ion / Li-MnO₂ |
| Shape | Ultra-Thin / Ultra-Small / Standard / Custom |
| Thickness | 1.0mm – 10.0mm |
| Protection | PCM / BMS Optional |
| Temperature Sensor | NTC Optional |
| Communication Load | Bluetooth |
| Cycle Life | 300–1000 Cycles |
| Certification Support | UN38.3 / IEC 62133-2 / CE / RoHS / MSDS |
Why Portable ECG Monitor Manufacturers Choose LithoTop
- Ultra-thin battery development capability
- Ultra-small medical LiPo battery customization
- Custom Li-ion battery pack engineering
- Li-MnO₂ primary battery solutions
- Grade-A lithium battery cells
- In-house PCM and BMS development
- Custom wires, connectors, tabs, and housings
- OEM and ODM prototype support
- Complete voltage, capacity, and safety inspection
- Global battery certification support
Please feel free to contact us for more information and customized battery solutions for your project.
Ultra-thin LiPo batteries are ideal for wearable ECG patches and compact patient monitoring devices that require lightweight construction, stable low-current discharge, and long monitoring duration.
- Ultra-thin profile for skin-mounted devices
- Lightweight structure for improved patient comfort
- High energy density within limited installation space
- Stable discharge for continuous ECG monitoring
- Custom thickness, width, and length available
- Optional PCM and NTC integration
Ultra-Thin Lipo Batteries List
| Model | Voltage(V) | Capacity(mAh) | Cell Dimension(mm) |
|---|---|---|---|
| 200815 | 3.7 | 9 | 2*8*15 |
| 201030 | 3.7 | 50 | 2*10*30 |
| 201821 | 3.7 | 45 | 2*18*21 |
| 202222 | 3.7 | 70 | 2*22*22 |
| 202935 | 3.7 | 130 | 2*29*35 |
| 203060 | 3.7 | 300 | 2*30*60 |
| 204045 | 3.7 | 300 | 2*40*45 |
| 204550 | 3.7 | 350 | 2*45*50 |
| 230922 | 3.7 | 27 | 2.3*9*22 |
| 232032 | 3.7 | 120 | 2.3*20*32 |
| 241330 | 3.7 | 65 | 2.4*13*30 |
| 241620 | 3.7 | 60 | 2.4*16*20 |
| 242222 | 3.7 | 90 | 2.4*22*22 |
| 250922 | 3.7 | 30 | 2.5*9*22 |
| 251020 | 3.7 | 20 | 2.5*10*20 |
| 251214 | 3.7 | 25 | 2.5*12*14 |
| 251235 | 3.7 | 70 | 2.5*12*14 |
| 251328 | 3.7 | 65 | 2.5*13*28 |
| 251330 | 3.7 | 70 | 2.5*13*30 |
| 251730 | 3.7 | 80 | 2.5*17*30 |
| 252022 | 3.7 | 85 | 2.5*20*22 |
| 252030 | 3.7 | 110 | 2.5*20*30 |
| 252040 | 3.7 | 180 | 2.5*20*40 |
| 252125 | 3.7 | 80 | 2.5*21*25 |
| 252828 | 3.7 | 150 | 2.5*28*28 |
| 252940 | 3.7 | 260 | 2.5*29*40 |
| 253057 | 3.7 | 500 | 2.5*30*57 |
| 262022 | 3.7 | 80 | 2.6*20*22 |
| 263347 | 3.8 | 500 | 2.6*33*47 |
| 271524 | 3.7 | 80 | 2.7*15*24 |
| 272647 | 3.7 | 300 | 2.7*26*47 |
| 281024 | 3.7 | 40 | 2.8*10*24 |
| 282028 | 3.7 | 140 | 2.8*20*28 |
| 283659 | 3.7 | 600 | 2.8*36*59 |
| 284057 | 3.7 | 700 | 2.8*40*57 |
Li-ion battery packs are designed for portable ECG systems with displays, data storage, wireless communication, printing, or multi-lead acquisition functions.
- Higher capacity for extended operation
- Stable power for displays and communication modules
- Custom series and parallel configurations
- Replaceable or built-in battery designs
- Optional PCM or BMS protection
- Custom housings, connectors, and chargers
Li-MnO₂ primary batteries are suitable for disposable, long-standby, and low-power cardiac monitoring devices that require reliable operation without recharging.
- Stable 3.0V nominal output
- Low self-discharge
- Long storage life
- Maintenance-free design
- Reliable low-current operation
- Suitable for disposable medical electronics
Li-MnO₂ Primary Batteries List
| Model | Voltage(V) | Capacity(mAh) | Std. discharge current(mA) | Max. continuous discharge current(mA) | Max. peak discharge current(mA) | Size(mm) | Weight(g) |
|---|---|---|---|---|---|---|---|
| CP042345 | 3 | 30 | 1 | 20 | 35 | 0.4*23*45 | 1 |
| CP2012120 | 3 | 480 | 1 | 50 | 80 | 2*13*127 | 5 |
| CP201535 | 3 | 120 | 1 | 30 | 60 | 2*15*35 | 2 |
| CP204142 | 3 | 500 | 1 | 150 | 300 | 2.2*41*42 | 6 |
| CP223565 | 3 | 750 | 1 | 200 | 500 | 2.5*36*66 | 6.5 |
| CP223830 | 3 | 400 | 1 | 60 | 120 | 2.2*38*30 | 4 |
| CP224035 | 3 | 550 | 1 | 150 | 300 | 2.5*41*36 | 5 |
| CP224147 | 3 | 800 | 1 | 200 | 400 | 2.2*45.5*48.3 | 6.5 |
| CP225040 | 3 | 750 | 1 | 200 | 500 | 2.5*51*41 | 7 |
| CP234044 | 3 | 650 | 1 | 200 | 400 | 2.5*41*43 | 6 |
| CP243742 | 3 | 700 | 1 | 200 | 300 | 2.6*38*43 | 6 |
| CP252025 | 3 | 220 | 1 | 80 | 150 | 2.5*20.5*25 | 2 |
| CP253025 | 3 | 220 | 1 | 30 | 50 | 2.7*31*26 | 2.5 |
| CP253428 | 3 | 250 | 1 | 200 | 400 | 2.4*34*28 | 2.5 |
| CP254442 | 3 | 800 | 1 | 200 | 400 | 2.7*44*42 | 6.5 |
| CP274136 | 3 | 650 | 1 | 150 | 300 | 2.7*41*36 | 6 |
| CP274142 | 3 | 850 | 1 | 200 | 400 | 2.8*41*42 | 7 |
| CP301536 | 3 | 300 | 0.5 | 50 | 100 | 3.2*16*37 | 3 |
| CP303330 | 3 | 560 | 1 | 150 | 300 | 3.2*33*30 | 4.5 |
| CP303047 | 3 | 1000 | 1 | 300 | 500 | 3*30*47 | 8 |
| CP304536 | 3 | 900 | 1 | 300 | 500 | 3*45*36 | 7 |
| CP304544 | 3 | 1300 | 5 | 300 | 500 | 3*46*45 | 11.5 |
| CP305050 | 3 | 1600 | 1 | 600 | 1200 | 3*50*50 | 14 |
| CP343130 | 3 | 600 | 1 | 200 | 400 | 3.4*31*31 | 6.5 |
| CP352440 | 3 | 650 | 1 | 200 | 500 | 3.5*25*42 | 6 |
| CP354328 | 3 | 700 | 1 | 200 | 400 | 3.5*43*28 | 5.5 |
| CP372525 | 3 | 400 | 1 | 80 | 150 | 3.7*25*25 | 4 |
| CP382025 | 3 | 350 | 1 | 100 | 200 | 4*20.5*25 | 3.5 |
| CP383047 | 3 | 1350 | 5 | 400 | 700 | 4*31*47 | 9.5 |
| CP401536 | 3 | 380 | 1 | 100 | 150 | 4*15*36 | 3.5 |
| CP402523 | 3 | 400 | 1 | 200 | 300 | 4*25*23 | 3.5 |
| CP403742 | 3 | 1400 | 5 | 600 | 1000 | 4.6*38*43 | 13 |
| CP404147 | 3 | 1800 | 5 | 600 | 1200 | 4*41*48 | 14 |
| CP405050 | 3 | 2500 | 5 | 800 | 1500 | 4.4*50*50 | 18 |
| CP443742 | 3 | 1500 | 1 | 600 | 800 | 4.6*38*43 | 13 |
| CP444844 | 3 | 1800 | 5 | 600 | 1500 | 4.4*48*44 | 14 |
| CP452124 | 3 | 420 | 1 | 100 | 200 | 4.5*21*24 | 3.5 |
| CP501932 | 3 | 600 | 1 | 200 | 300 | 5.2*20*33 | 6 |
| CP502025 | 3 | 400 | 1 | 100 | 200 | 5.2*20.5*25 | 3.5 |
| CP502425 | 3 | 550 | 1 | 250 | 300 | 5.2*25*25 | 5.5 |
| CP502432 | 3 | 700 | 1 | 150 | 300 | 5.2*24*32.5 | 6 |
| CP502440 | 3 | 1200 | 1 | 120 | 400 | 5.2*24*41 | 8 |
| CP502525 | 3 | 550 | 1 | 200 | 400 | 5.2*26*26 | 4.5 |
| CP503333 | 3 | 1200 | 1 | 400 | 800 | 5*34*34 | 9 |
| CP503742 | 3 | 1900 | 5 | 800 | 1000 | 5.2*38*43 | 16 |
| CP504644 | 3 | 2400 | 5 | 1000 | 2000 | 5.2*46*44 | 17 |
| CP505050 | 3 | 3000 | 10 | 1200 | 2500 | 5.2*50*50 | 23 |
| CP553536 | 3 | 1600 | 5 | 600 | 1200 | 5.5*35*37 | 11 |
| CP603132 | 3 | 1200 | 5 | 500 | 1000 | 6.2*32*33 | 11 |
| CP603147 | 3 | 1950 | 5 | 800 | 1200 | 6*31*47 | 16 |
| CP603450 | 3 | 2300 | 5 | 1200 | 1500 | 6.2*35*51 | 18 |
| CP603956 | 3 | 3200 | 5 | 1500 | 2000 | 6.2*40*57 | 25 |
| CP652230 | 3 | 800 | 5 | 300 | 500 | 6.7*23*31 | 7 |
| CP702440 | 3 | 1500 | 5 | 300 | 600 | 7*24.5*41 | 11 |
| CP705050 | 3 | 4000 | 5 | 1500 | 3000 | 7.2*50*51 | 32 |
| CP752425 | 3 | 900 | 1 | 250 | 500 | 7.7*25*25 | 7 |
| CP7839109 | 3 | 10000 | 1 | 3000 | 5000 | 8*40*110 | 63 |
| CP802030 | 3 | 800 | 1 | 100 | 200 | 8.1*20*30 | 6 |
| CP952434 | 3 | 1600 | 5 | 300 | 600 | 9.5*25*35 | 11 |
| CP1005050 | 3 | 6000 | 5 | 2000 | 5000 | 10.2*50*51 | 50 |
| CP1202425 | 3 | 1350 | 1 | 450 | 1125 | 12*25*26 | 9 |
Frequently Asked Questions
What battery is commonly used in portable ECG monitors?
Portable ECG monitors commonly use rechargeable LiPo or Li-ion batteries. Ultra-thin LiPo batteries are especially suitable for wearable ECG patches, while higher-capacity Li-ion battery packs are used in portable multi-lead ECG machines.
What battery is suitable for a wearable ECG patch?
Ultra-thin LiPo batteries are suitable for rechargeable wearable ECG patches because they provide a thin profile, lightweight construction, and stable output. Disposable ECG patches may use compact primary lithium batteries depending on operating duration and product design.
Can LithoTop customize batteries for Holter monitors?
Yes. LithoTop can customize battery voltage, capacity, thickness, dimensions, wire length, connectors, tabs, PCM protection, NTC sensors, and packaging for Holter monitors and portable ECG equipment.
Can the battery support Bluetooth or cellular transmission?
Yes. The battery can be engineered to support the standby current and transmission-current peaks generated by Bluetooth, Wi-Fi, or cellular modules. The final design should be based on the device’s actual current profile.
Does LithoTop support batteries for portable 12-lead ECG machines?
Yes. LithoTop can develop higher-capacity Li-ion battery packs for portable ECG machines with displays, data storage, printing, wireless communication, and multi-lead acquisition functions.
