Medical robots are rapidly transforming modern healthcare by improving surgical precision, patient care, rehabilitation efficiency, hospital logistics, and diagnostic accuracy. From robotic-assisted surgery and rehabilitation systems to autonomous hospital service robots, reliable battery performance is essential for continuous operation and patient safety.
Compared with conventional industrial robots, medical robots demand compact battery systems with high energy density, exceptional reliability, stable voltage output, and advanced safety protection. Battery performance directly affects mobility, operating time, equipment reliability, and regulatory compliance.
LithoTop provides customized lithium battery solutions for medical robotics manufacturers, supporting high-energy LiPo batteries, Li-ion battery packs, LiFePO₄ battery packs, and high-discharge lithium battery systems for OEM and ODM projects.
Challenges of Medical Robot Battery Design
Continuous Operation
Medical robots often operate continuously throughout the day in hospitals, laboratories, and rehabilitation centers. Battery systems must provide reliable power for extended operation without compromising performance.
- Long runtime
- Stable voltage output
- Fast charging capability
- Reliable continuous operation
High Safety Requirements
Medical environments require battery systems with exceptional safety and reliability to protect both patients and healthcare professionals.
- Grade-A lithium cells
- Overcharge protection
- Over-discharge protection
- Short-circuit protection
- Temperature monitoring
- 100% quality inspection
Compact System Integration
Medical robots integrate numerous electronic modules, sensors, communication systems, and controllers within limited installation space.
- Compact battery packs
- High energy density
- Custom battery layouts
- Flexible mechanical design
Stable Power for Precision Motion
Robotic arms, servo motors, navigation systems, and precision control units require batteries capable of delivering stable current with minimal voltage fluctuation.
- High continuous current output
- Low voltage drop
- Stable discharge performance
- Reliable motor power supply
LithoTop Battery Solutions for Medical Robots
High Energy Density LiPo Batteries
High energy density lithium polymer batteries are ideal for portable and mobile medical robots where lightweight construction and long operating time are critical. Their superior energy-to-weight ratio helps maximize mobility while reducing overall robot weight.
- High energy density for longer runtime
- Lightweight construction
- Stable voltage output
- Custom voltage and capacity
- Suitable for surgical and diagnostic robots
Li-ion Battery Packs
Custom Li-ion battery packs provide high-capacity power solutions for hospital service robots, rehabilitation systems, medical AGVs, and intelligent healthcare equipment requiring long operating hours and dependable performance.
- High-capacity battery packs
- Stable power delivery
- Long operating time
- Multiple voltage configurations
- Custom OEM battery pack solutions
LiFePO₄ Battery Packs
LiFePO₄ battery technology offers excellent thermal stability, outstanding safety, and extremely long cycle life. It is an excellent choice for medical robots that operate continuously in hospitals and healthcare facilities.
- Excellent thermal stability
- Long cycle life
- Enhanced safety performance
- Stable discharge voltage
- Ideal for hospital logistics robots
High-Discharge Lithium Battery Packs
Medical robots equipped with robotic arms, lifting systems, servo motors, or mobile drive platforms often require high current output. LithoTop’s high-discharge lithium battery packs provide stable power during acceleration, precision movement, and dynamic load conditions.
- High continuous discharge capability
- High peak current support
- Reduced voltage sag
- Stable motor performance
- Suitable for robotic arms and powered rehabilitation equipment
Medical Robot Battery Features
- High Energy Density
- Long Operating Runtime
- Medical-Grade Safety
- Stable Voltage Output
- Lightweight Construction
- High Continuous Current Capability
- Long Cycle Life
- Excellent Thermal Stability
- Custom Battery Pack Design
- OEM & ODM Manufacturing Support
Typical Battery Specifications for Medical Robots
| Parameter | Typical Range |
|---|---|
| Voltage | 7.4V – 51.8V |
| Configuration | 2S – 14S |
| Capacity | 2Ah – 50Ah |
| Battery Type | LiPo / Li-ion / LiFePO₄ |
| Continuous Current | 5A – 200A |
| Peak Current | Up to 400A |
| Cycle Life | 500 – 3000 Cycles |
| Communication | CAN Bus / SMBus / UART (Optional) |
| Certifications | UN38.3 / IEC62133 / CE / RoHS / MSDS |
Why Medical Robot Manufacturers Choose LithoTop
- Grade-A lithium battery cells
- Medical battery development expertise
- Custom battery pack engineering
- In-house PCM & BMS development
- High energy density battery solutions
- Fast prototype development
- OEM & ODM manufacturing support
- 100% inspection before shipment
- Global certification support
Please feel free to contact us for more information and customized battery solutions for your project.
LithoTop develops high energy density lithium polymer (LiPo) battery solutions specifically engineered for medical robots and intelligent healthcare equipment. These lightweight battery packs provide longer operating time while minimizing overall system weight, making them ideal for mobile medical robots, surgical robots, rehabilitation robots, and autonomous healthcare devices.
Our high energy density LiPo batteries can be fully customized according to your project requirements, including voltage, capacity, dimensions, discharge rate, connectors, communication interfaces, and protection circuits. Every battery pack is manufactured using Grade-A lithium cells and undergoes 100% quality inspection to ensure stable performance and long-term reliability.
- High energy density for extended operating time
- Lightweight construction for improved robot mobility
- Stable voltage output and excellent discharge performance
- Custom voltage, capacity, connectors and battery dimensions
- Grade-A lithium cells with long cycle life
- OEM & ODM battery pack customization support
High Energy Density LiPo Batteries List
| Model | Voltage(V) | Capacity(mAh) | Cell Size(T*W*L)mm | Shape |
|---|---|---|---|---|
| 500830 | 3.7 | 110 | 5*8*30 | Pouch |
| 500922 | 3.7 | 65 | 5*9*22 | Pouch |
| 500935 | 3.7 | 130 | 5*9*35 | Pouch |
| 501010 | 3.7 | 35 | 5*10*10 | Pouch |
| 501012 | 3.7 | 40 | 5*10*12 | Pouch |
| 501015 | 3.7 | 50 | 5*10*15 | Pouch |
| 501030 | 3.7 | 120 | 5*10*30 | Pouch |
| 501035 | 3.7 | 130 | 5*10*35 | Pouch |
| 501038 | 3.7 | 160 | 5*10*38 | Pouch |
| 501040 | 3.7 | 180 | 5*10*40 | Pouch |
| 501114 | 3.7 | 50 | 5*11*14 | Pouch |
| 501120 | 3.7 | 100 | 5*11*20 | Pouch |
| 501130 | 3.7 | 150 | 5*11*30 | Pouch |
| 501145 | 3.7 | 250 | 5*11*45 | Pouch |
| 501215 | 3.7 | 60 | 5*12*15 | Pouch |
| 501220 | 3.7 | 100 | 5*12*20 | Pouch |
| 501225 | 3.7 | 120 | 5*12*25 | Pouch |
| 501228 | 3.7 | 150 | 5*12*28 | Pouch |
| 501230 | 3.7 | 130 | 5*12*30 | Pouch |
| 501235 | 3.7 | 150 | 5*12*35 | Pouch |
| 501240 | 3.7 | 200 | 5*12*40 | Pouch |
| 501245 | 3.7 | 260 | 5*12*45 | Pouch |
| 501314 | 3.7 | 65 | 5*13*14 | Pouch |
| 501321 | 3.7 | 105 | 5*13*21 | Pouch |
| 501323 | 3.7 | 120 | 5*13*23 | Pouch |
| 501332 | 3.7 | 170 | 5*13*32 | Pouch |
| 501420 | 3.7 | 95 | 5*14*20 | Pouch |
| 501447 | 3.7 | 280 | 5*14*47 | Pouch |
| 501515 | 3.7 | 80 | 5*15*15 | Pouch |
| 501520 | 3.7 | 125 | 5*15*20 | Pouch |
| 501522 | 3.7 | 130 | 5*15*22 | Pouch |
| 501524 | 3.7 | 170 | 5*15*24 | Pouch |
| 501530 | 3.7 | 200 | 5*15*30 | Pouch |
| 501535 | 3.7 | 240 | 5*15*35 | Pouch |
| 501622 | 3.7 | 140 | 5*16*22 | Pouch |
| 501645 | 3.7 | 340 | 5*16*45 | Pouch |
| 501723 | 3.7 | 160 | 5*17*23 | Pouch |
| 501725 | 3.8 | 230 | 5*17*25 | Pouch |
| 501730 | 3.7 | 200 | 5*17*30 | Pouch |
| 501735 | 3.7 | 300 | 5*17*35 | Pouch |
| 501818 | 3.7 | 150 | 5*18*18 | Pouch |
| 501825 | 3.7 | 180 | 5*18*25 | Pouch |
| 501880 | 3.7 | 300 | 5*18*80 | Pouch |
| 502020 | 3.7 | 150 | 5*20*20 | Pouch |
| 502025 | 3.7 | 200 | 5*20*25 | Pouch |
| 502028 | 3.7 | 250 | 5*20*28 | Pouch |
| 502030 | 3.7 | 320 | 5*20*30 | Pouch |
| 502035 | 3.7 | 350 | 5*20*35 | Pouch |
| 502035 | 3.8 | 400 | 5*20*35 | Pouch |
| 502040 | 3.7 | 400 | 5*20*40 | Pouch |
| 502045 | 3.7 | 450 | 5*20*45 | Pouch |
| 502050 | 3.7 | 500 | 5*20*50 | Pouch |
| 502060 | 3.7 | 600 | 5*20*60 | Pouch |
| 502065 | 3.7 | 700 | 5*20*65 | Pouch |
| 502080 | 3.7 | 900 | 5*20*80 | Pouch |
| 502235 | 3.7 | 365 | 5*22*35 | Pouch |
| 502243 | 3.7 | 460 | 5*22*43 | Pouch |
| 502248 | 3.7 | 520 | 5*22*48 | Pouch |
| 502260 | 3.7 | 600 | 5*22*60 | Pouch |
| 502270 | 3.7 | 900 | 5*22*70 | Pouch |
| 502325 | 3.7 | 260 | 5*23*25 | Pouch |
| 502525 | 3.7 | 300 | 5*25*25 | Pouch |
| 502530 | 3.7 | 350 | 5*25*30 | Pouch |
| 502535 | 3.7 | 450 | 5*25*35 | Pouch |
| 502540 | 3.7 | 500 | 5*25*40 | Pouch |
| 502560 | 3.7 | 900 | 5*25*60 | Pouch |
| 502728 | 3.7 | 400 | 5*27*28 | Pouch |
| 502828 | 3.8 | 500 | 5*28*28 | Pouch |
| 503030 | 3.7 | 400 | 5*30*30 | Pouch |
| 503035 | 3.7 | 520 | 5*30*35 | Pouch |
| 503040 | 3.7 | 600 | 5*30*40 | Pouch |
| 503048 | 3.7 | 750 | 5*30*48 | Pouch |
| 503065 | 3.7 | 1200 | 5*30*65 | Pouch |
| 503450 | 3.7 | 1000 | 5*34*50 | Pouch |
| 503560 | 3.7 | 1200 | 5*35*60 | Pouch |
| 503759 | 3.7 | 1200 | 5*37*59 | Pouch |
| 504045 | 3.7 | 900 | 5*40*45 | Pouch |
| 504065 | 3.7 | 1500 | 5*40*65 | Pouch |
| 504070 | 3.7 | 1200 | 5*40*70 | Pouch |
| 505050 | 3.7 | 1500 | 5*50*50 | Pouch |
| 505060 | 3.7 | 2000 | 5*50*60 | Pouch |
| 505080 | 3.7 | 2200 | 5*50*80 | Pouch |
| 5050100 | 3.7 | 4000 | 5*50*100 | Pouch |
| 505573 | 3.7 | 2500 | 5*55*73 | Pouch |
| 506090 | 3.7 | 3000 | 5*60*90 | Pouch |
| 521012 | 3.7 | 45 | 5.2*10*12 | Pouch |
| 521220 | 3.7 | 90 | 5.2*12*20 | Pouch |
| 521417 | 3.7 | 100 | 5.2*14*17 | Pouch |
| 521525 | 3.7 | 170 | 5.2*15*25 | Pouch |
| 522030 | 3.7 | 280 | 5.2*20*30 | Pouch |
| 522035 | 3.8 | 400 | 5.2*20*35 | Pouch |
| 522540 | 3.8 | 680 | 5.2*25*40 | Pouch |
| 522830 | 3.8 | 560 | 5.2*28*30 | Pouch |
| 523450 | 3.8 | 1250 | 5.2*34*50 | Pouch |
| 531525 | 3.7 | 180 | 5.3*15*25 | Pouch |
| 551015 | 3.7 | 55 | 5.5*10*15 | Pouch |
| 551045 | 3.7 | 250 | 5.5*10*45 | Pouch |
| 551220 | 3.7 | 110 | 5.5*12*20 | Pouch |
| 551225 | 3.7 | 160 | 5.5*12*25 | Pouch |
| 551235 | 3.7 | 180 | 5.5*12*35 | Pouch |
| 551240 | 3.7 | 230 | 5.5*12*40 | Pouch |
| 551245 | 3.7 | 250 | 5.5*12*45 | Pouch |
| 551520 | 3.7 | 150 | 5.5*15*20 | Pouch |
| 551525 | 3.7 | 180 | 5.5*15*25 | Pouch |
| 551535 | 3.7 | 240 | 5.5*15*35 | Pouch |
| 551730 | 3.7 | 220 | 5.5*17*30 | Pouch |
| 551735 | 3.7 | 320 | 5.5*17*35 | Pouch |
| 552035 | 3.7 | 350 | 5.5*20*35 | Pouch |
| 552040 | 3.7 | 400 | 5.5*20*40 | Pouch |
| 552065 | 3.7 | 800 | 5.5*20*65 | Pouch |
| 552225 | 3.7 | 250 | 5.5*22*25 | Pouch |
| 552230 | 3.7 | 320 | 5.5*22*30 | Pouch |
| 552240 | 3.7 | 400 | 5.5*22*40 | Pouch |
| 552248 | 3.7 | 600 | 5.5*22*48 | Pouch |
| 552530 | 3.7 | 350 | 5.5*25*30 | Pouch |
| 552535 | 3.7 | 450 | 5.5*25*35 | Pouch |
| 552548 | 3.7 | 600 | 5.5*25*48 | Pouch |
| 552728 | 3.7 | 400 | 5.5*27*28 | Pouch |
| 553035 | 3.7 | 600 | 5.5*30*35 | Pouch |
| 552530 | 3.7 | 350 | 5.5*25*30 | Pouch |
| 552548 | 3.7 | 700 | 5.5*25*48 | Pouch |
| 552728 | 3.7 | 400 | 5.5*27*28 | Pouch |
| 553035 | 3.7 | 600 | 5.5*30*35 | Pouch |
| 555056 | 3.7 | 2100 | 5.5*50*56 | Pouch |
| 555075 | 3.7 | 2500 | 5.5*55*75 | Pouch |
| 5565113 | 3.7 | 5000 | 5.5*65*113 | Pouch |
| 581015 | 3.7 | 60 | 5.8*10*15 | Pouch |
| 581525 | 3.7 | 180 | 5.8*15*25 | Pouch |
| 582525 | 3.7 | 350 | 5.8*25*25 | Pouch |
LithoTop provides custom rechargeable Li-ion battery packs designed for medical robots that require high capacity, reliable power delivery, and extended operating hours. Our battery packs are widely used in hospital service robots, rehabilitation robots, medical AGVs, diagnostic robots, and autonomous healthcare systems.
With in-house battery pack assembly and PCM/BMS development capabilities, LithoTop supports customized battery configurations, communication protocols, wiring harnesses, connectors, and enclosure designs to meet the demanding requirements of medical robotic applications.
- High-capacity battery pack solutions for long operating time
- Stable power output for precision robotic systems
- Custom battery configurations from 2S to 14S
- Optional CAN Bus, RS485 and UART communication
- Integrated PCM/BMS protection for enhanced safety
- OEM & ODM design and manufacturing support
LithoTop manufactures high-performance LiFePO₄ battery packs for medical robots that demand exceptional safety, long service life, and reliable operation. Thanks to their excellent thermal stability and extended cycle life, LiFePO₄ batteries are an ideal choice for hospital logistics robots, medical delivery robots, rehabilitation systems, and healthcare automation equipment.
Our custom LiFePO₄ battery packs are available in various voltages, capacities, and configurations, with optional smart battery management systems, communication interfaces, and customized connectors to support continuous medical operations.
- Outstanding thermal and chemical stability
- Long cycle life exceeding 2,000 cycles
- Excellent safety for medical applications
- Stable voltage output under continuous operation
- Custom battery packs with PCM/BMS integration
- Suitable for hospital service robots and medical AGVs
FAQ
What batteries are commonly used in medical robots?
Most medical robots use rechargeable Li-ion battery packs, high-energy LiPo batteries, LiFePO₄ batteries, or high-discharge lithium battery packs depending on their operating requirements.
Can LithoTop customize battery packs for medical robots?
Yes. LithoTop provides custom voltage, capacity, dimensions, connectors, communication interfaces, and battery pack structures for medical robotics OEM projects.
Why are LiFePO₄ batteries used in medical robots?
LiFePO₄ batteries offer excellent safety, long cycle life, and outstanding thermal stability, making them ideal for hospital service robots and healthcare automation equipment.
Does LithoTop provide complete battery pack solutions?
Yes. LithoTop offers complete battery solutions including battery cells, PCM/BMS, wiring harnesses, connectors, housings, chargers, and certification support.
